Enabling accurate and efficient EMC & RF Measurements
Measure the Difference
Raditeq offers a diverse and vast amount of EMC Test & Measurement instrumentation like, Electric Field probes, Electric Field Generators, RF Power Meters and Modular Test Systems. Check them out and measure the difference now!
EMC is a difficult subject with lots of obstacles and hard challenges. Raditeq offers turnkey solutions for EMC, High Frequency (HF) Radio Frequency (RF) and microwave applications.
Do you need assistance or information about products, projects, Return Material Authorization (RMA), Service level agreements or any other related questions? The Raditeq support team is ready and at your service.
Special Microwave projects
Raditeq designs and develops analog radio frequency (RF) electronics. Knowledge in the field of RF technology is scarce. Knowledge in the field of analog RF filters, mixers, amplifiers and antenna even more so. Together with the engineers at Raditeq you gain the required expertise to make your HF, RF, Uwave and EMC challenges a great succes.
Events & Webinars
Raditeq continues with the subject, isotropy. The forgotten aspect when in comes to measurement reliability and accuracy. Join the webinar about this sometimes mind boggling
Raditeq will be present at the 2021 EMV Mesago event in Stuttgart. When COVID-19 doesn’t spoil the fun look us up on stand number; C2-316
- BMW: Innovative EMC Hall for Realistic Vehicle Testing emv GmbH has provided a turnkey EMC measurement system for the BMW Group and shared in the conception and planning of the whole project.
A modern automobile requires a complex network of electronic systems. These control essentials such as the motor and transmission as well as various safety and comfort features such as dynamic stability control (DSC) and satellite supported GPS navigation. The problem is that these systems can affect each other or be disturbed by electromagnetic signals from the surroundings. The automobile manufacturers must detect, diagnose, and correct such system problems by means of EMC testing.
Until recently, in the existing BMW Group EMC hall, most EMC tests could only be performed on stationary vehicles. So BMW decide to build a state of the art EMC absorber hall at their research and innovation center in Munich.
The new EMC hall should permit BMW engineers to test networked systems with realistic dynamic vehicle situations. Antennas were needed to provide strong high frequency signals and these had to be dynamically oriented and moved in the hall and brought as near as possible to the vehicle on the turntable (11 m diameter). The desired test scenarios also required a large unimpeded floor area in the measurement hall. All this had to be combined with very efficient test sequencing and ease of measurement.
The task was solved by attaching the flexible antenna complex to the roof of the hall. The antenna is exactly positioned relative to the tested vehicle, using six-axis remote control. It can be lowered from the roof as near as wanted to the vehicle. This leaves the floor free for simulation of all sorts of driving situations. emv solved the requirements for efficient ergonomic measurement by various means. The high level of automation of the Measurement system makes the difference. The engineers can now carry out a set of tests according to BMW standards just by pressing a button. The antenna configuration can be automatically set according to vehicle type. The RadiMation“ software from Dare!! organizes this. For instance, the software organizes the integration of dynamometer, turntable and antenna controller from different manufacturers. For immunity tests, the frequency range 20 MHz to 4 GHz, can be measured without changing the antenna configuration.
The low frequency range is covered by a 200 Ohm stripline solution. This was developed by specialists from the EMC department of the BMW Group and has been patented. It can be set up and taken down again within five minutes, and takes up little space when packed together.
EUT monitoring lets the test engineer watch and document the behavior of the test object while checking out the fieldbus in the vehicle. A modular concept permits communication with different fieldbuses (e.g. CAN, LIN) via one base cable. A Car Radio Dummy is used to check the correct functioning of measurements of radiated interference. The vehicle antenna receives the radio signal, and the Car Radio Dummy sends it back to the measurement receiver in the measurement controller, where it is verified. Radio signals in the frequency range 100 kHz to 4.2 GHz are generated by semiconductor amplifiers from AR. A microwave rack with 500 watt TWT amplifiers and filters for harmonic suppression covers the frequency range 2.5 GHz to 18 GHz. A GPS simulator supports simulation of realistic routes. Real GPS signals and transmissions from real radio stations can be received by an external antenna and communicated into the hall.
The new EMC hall is the first of its kind in the world. It makes possible the testing of driver-assistance systems under reproducible lab conditions in moving vehicles. Curbstones, parking spaces, passing vehicles and specific routes can all be simulated in order to test electronic systems under realistic conditions.
The project was completed in 2 years. "The deciding factor for the success of this joint project was the collegial cooperation between BMW experts and our project team", stated Markus Krautbauer, project manager at emv GmbH.
- Barco N.V | RadiField® Triple A"At Barco, we constantly strive to test our products in a cost-effective and efficient way at our EMC lab.
As the two EMC standards that apply to our technology were updated, we were confronted with increased levels on radiated immunity testing for medical equipment and an increase in the frequency range in CISPR 35 compared to CISPR 24.
Thanks to the Radifield® proposed by Raditeq (Dare!!), we could anticipate testing that enabled us to validate the proposed solution against the new requirements. For us, this proposal had the fastest return on investment. After that, sending out the purchase order was only a formality. In the meantime the Barco EMC lab is fully future proof, just as our products."Dora DeboeureBarco N.V
- Barco N.V | RadiSense® 10‘At Barco N.V. located in Courtrai (Kortrijk) Belgium we have gained very positive experiences with the RadiSense IV (previous model) operating in our EMC labs. This experiences, combined with a very attractive trade-in offer we got from Raditeq (DARE!!), made us decide to buy the new model RadiSense® 10. Furthermore, the fact that the RadiSense® 10 is supported by different EMC test software packages we use at Barco was an important contributing reason. The RadiSense 10 probe is used for radiated immunity testing applications.’Steven RaevensBarco N.V.
